DS-8664NI-I8 NVR

DS-8664NI-I8 NVR

Product Details:

X

Product Description

Model DS-8664NI-I8
IP video input 64-ch
Incoming bandwidth 320Mbps
Outgoing bandwidth 256Mpbs
VGA1/HDMI1 output resolution HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA2/HDMI2 output resolution HDMI2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA2: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio output 2-ch, RCA (Linear, 1 K Ω)
Decoding format H.265/H.264/MPEG4
Recording resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/ QCIF
Synchronous playback 16-ch
Capability 4-ch@4K/16-ch@1080p
SATA 8 SATA interfaces
eSATA 1 eSATA interface
Capacity 500GB/1TB/2TB/3TB/4TB/5TB/6TB
Two-way audio 1-ch, RCA (2.0 Vp-p, 1 kΩ)
Network interface 2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
Serial interface RS-232; RS-485; Keyboard
USB interface Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
Alarm in/out 16/4
Power supply 100 to 240 VAC, 50 to 60 Hz
Consumption (without hard disk) ≤ 35 W
Max. Power 200 W
Working temperature -10 to +55°C (14 to 131°F)
Working humidity 10% to 90%
Chassis 19-inch rack-mounted 2U chassis
Dimensions(W × D × H) 445 × 470 ×90 mm ( 17.5”× 18.3” × 3.5”)
Weight(without hard disks) ≤8Kg(17.6lb)
