EZVIZ CS-TY1-B0-1G2WF

EZVIZ CS-TY1-B0-1G2WF

Product Details:

  • Warranty 2 YEARS
  • Dimension(L*W*H) 88 x 88 x 118.7 mm (3.46 x 3.46 x 4.67 inch
  • Camera Type IP Camera
  • Sensor Type CMOS
  • Camera Style Dome Camera
  • Technology Wi-fi
  • Application Restaurant, Hotels, Indoor
X

Product Specifications

  • CMOS
  • 2 YEARS
  • Wi-fi
  • DC 5V/1A
  • 88 x 88 x 118.7 mm (3.46 x 3.46 x 4.67 inch
  • 2 Megapixel (MP )
  • 103 x 103 x 186 mm (4.06 x 4.06 x 7.32 inch)
  • 1920 × 1080
  • IP Camera
  • Dome Camera
  • Restaurant, Hotels, Indoor

Product Description

Image Sensor 1/3" Progressive Scan CMOSShutter Speed Self-adaptive shutterLens 4mm@ F2.4, view angle: 85° diagonal, 75° horizontal, 45° vertical Lens Mount M12Day & NightDNRWDRIR-cut filter with auto-switching3D DNRDigital WDR


Video Compression H.264Video Bit Rate Adaptive bit rate


Max. Resolution 1920 × 1080Frame Rate Max:15fps; Self-Adaptive during network transmission


Smart Alarm Motion detectionWi-Fi Pairing AP pairing Protocol EZVIZ Cloud proprietary protocolInterface Protocol EZVIZ Cloud proprietary protocol


Storage MicroSD card slot (Max. 256GB)Power Micro USBWired Network RJ45 X 1 (10M/100M self-adaptive Ethernet port)


Standard IEEE802.11b/g/n Frequency Range 2.4 GHz ~ 2.4835 GHzChannel Bandwidth Supports 20MHzSecurity 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSKTransmission Rate 11b: 11Mbps, 11g: 54Mbps, 11n: 72Mbps


Temperature -10°C to 45°C (14°F to 113 °F)Humidity 95% or less (non-condensing)


Power Supply DC 5V/1APower Consumption 5W maxIR Range MAX. 10 meters (32.81 ft.)Dimensions Packaging DimensionsNet Weight88 x 88 x 118.7 mm (3.46 x 3.46 x 4.67 inch)259g (9.14oz)
