HIKVISION DS-7B08HGHI-F1

Get a Price/Quote

HIKVISION DS-7B08HGHI-F1 Specification

Connectivity Type
BNC input, HDMI, VGA, USB, LAN

Camera Range
Up to 1200 m for 720P HD-TVI signal

Camera Type
DVR for CCTV cameras

Sensor Type
Compatible with analog and HD-TVI cameras

Camera Style
Supports multiple styles (Dome/Bullet/PTZ)

Technology
HDTVI, Analog, AHD, CVI, IP

Special Features
HDTVI 2.0, Turbo HD, Long-distance transmission

Remote Control
Supported via Hik-Connect

Application
Video surveillance for homes, offices, shops

Camera Size
Compatible with standard analog camera sizes

Camera Pixels
Supports up to 2 MP (1080P Lite)

Screen Resolution
1920 x 1080 (HDMI/VGA output)

Image/Video Quality
1080P Lite/720P real-time recording

Power Supply
12V DC

Output Formats
1 HDMI, 1 VGA simultaneous output

File Compatibility
H.264+ / H.264 encoding

HIKVISION DS-7B08HGHI-F1 Trade Information

Payment Terms
Cash on Delivery (COD), Cash in Advance (CID), Cash Advance (CA)

Main Export Market(s)
Asia

About HIKVISION DS-7B08HGHI-F1

Technical Specification

Resolution	When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIFWhen 1080p Lite mode enabled: 1080p lite/720p
Brand	HIKVISION
Model Name/Number	DS-7B08HGHI-F1
Type	DVR
Stream Type	Video, Video & Audio
Audio Input	1-ch
Usage/Application	Video Recording
Camera Technology	Analog Camera

Video Input and Transmission

Connectable to Turbo HD/HDCVI/AHD/CVBS signal input
Long distance transmission over UTP and coaxial cable: max. 1200m for 720p Turbo HD signal

Compression and Recording

One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
Supports 1080p lite of all channels and when enabled, the image effect is similar with 1080p

Video Output

HDMI/VGA output at up to 1920- 1080 resolution

Flexible Compatibility

The DS-7B08HGHI-F1 supports a wide array of camera technologies including HDTVI, Analog, AHD, CVI, and IP. This flexibility makes integration seamless, whether upgrading legacy systems or deploying new installations. Its multi-style camera compatibility allows use of dome, bullet, and PTZ cameras, simplifying procurement and installation across different surveillance objectives.

Enhanced Recording and Storage

Advanced recording resolutions such as 1080P Lite, 720P, and WD1 ensure clear and detailed footage. With support for one SATA HDD up to 6TB, the device is capable of archiving significant amounts of video data, minimizing the need for frequent backup interventions. Dual USB 2.0 ports and network connectivity further streamline export and backup processes.

Remote Monitoring and Control

Remote access is enabled through Hik-Connect, allowing users to view live or recorded footage from anywhere via their smartphone or PC. The DVR is equipped with network protocols like TCP/IP, DHCP, NTP, and more, ensuring secure, uninterrupted connectivity and hassle-free management of surveillance operations.

FAQ's of HIKVISION DS-7B08HGHI-F1:

Q: How do I connect cameras to the HIKVISION DS-7B08HGHI-F1 DVR?

A: You can connect up to eight analog or HD-TVI cameras using the BNC inputs. The DVR supports multiple camera styles, including dome, bullet, and PTZ, offering flexible installation options for various surveillance needs.

Q: What is the maximum video recording resolution supported by this DVR?

A: The DS-7B08HGHI-F1 supports recording at 1080P Lite, 720P, WD1, 4CIF, VGA, and CIF resolutions, with real-time frame rates of 25/30 fps per channel. HDMI and VGA outputs deliver up to a 1920 x 1080 screen resolution.

Q: When should I backup my surveillance footage and how can I do it?

A: It's recommended to perform backups regularly, especially after significant events. You can backup footage via a USB device or through your network connection, ensuring your data remains secure and retrievable.

Q: Where can I access live video remotely from this DVR?

A: Remote viewing is possible through Hik-Connect, Hikvision's remote monitoring application, which is accessible on both smartphones and PCs. This feature allows for convenient oversight from any location with internet access.

Q: What advantages does long-distance transmission offer?

A: The HDTVI 2.0 technology supports long-distance transmission of HD video signals, reaching up to 1200 meters for 720P signals. This enables camera placement far from the DVR without sacrificing image quality.

Q: How does the device handle simultaneous video outputs?

A: The DVR provides simultaneous HDMI and VGA outputs, allowing you to connect to two monitors at once. This feature is beneficial for multi-view setups in control rooms or offices.

Q: What power requirements and environmental conditions does the device support?

A: Powered by a 12V DC supply, the DVR operates efficiently within a temperature range of -10C to +55C. Its robust design ensures reliable functioning in varied Indian climate conditions.
